Fuel Injector Resistor
WARNING:
DO NOT smoke during the test. Keep open flame away from your work area. ALWAYS release fuel pressure before disconnecting any fuel injection-related component. DO NOT allow fuel to contact engine or electrical components.
- Disconnect the fuel injector resistor connector. See Fig 1 .
- Check for resistance between each of the fuel injector resistor terminals B, C, D, F, G, H and the power terminal E.
- Resistance should be 5-7 ohms.
- Replace the fuel injector resistor with a new one if any of the resistances are outside of the specification.
