Intake Air Resonator Removal/Installation

Remove the splash separator (A)

Fig 1: Identifying Splash Separator
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Do the battery removal procedure (see BATTERY REMOVAL AND INSTALLATION )
Remove the air cleaner (see THROTTLE BODY CLEANING )
Remove the battery base (A)

Fig 2: Battery Base With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the intake air duct (A)

Fig 3: Identifying Intake Air Duct
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the front bumper (see FRONT BUMPER REMOVAL/INSTALLATION )
Remove the intake air resonator (A)

Fig 4: Intake Air Resonator With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.
J37A4 engine: Remove the brake duct (B).
Install the parts in the reverse order of removal
Do the battery installation procedure (see BATTERY REMOVAL AND INSTALLATION )
