DTC B1835: Steering Column Manual Switch Malfunction

NOTE: If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Clear the DTC with the HDS.
Turn the ignition switch to LOCK (0) and then back to ON (II).
Operate the tilt/telescopic switch in each direction for at least 3 seconds each.
Check for DTCs with the HDS.
Is DTC B1835 indicated?

YES -Go to step 5.

NO -Intermittent failure, the power tilt/telescopic steering system is OK at this time. Check for loose or poor connections at the tilt/telescopic switch connector and at the power tilt/telescopic control unit connectors.
Turn the ignition switch to LOCK (0).
Do the tilt/telescopic switch test (see POWER TILT/TELESCOPIC STEERING SWITCH TEST/REPLACEMENT ).
Is the switch OK?

YES -Go to step 7.

NO -Replace the switch (see POWER TILT/TELESCOPIC STEERING SWITCH TEST/REPLACEMENT ).
Disconnect power tilt/telescopic steering control unit connector A (16P).
Disconnect the tilt/telescopic switch 13P connector.
Check for continuity between body ground and tilt/telescopic switch 13P connector terminals No. 1, No. 3, No. 6, No. 7, and No. 10 individually.

Fig 1: Checking Continuity Between Body Ground And Tilt/Telescopic Switch 13P Connector Terminals No. 1, No. 3, No. 6, No. 7 And No. 10
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there continuity?

YES -Repair a short to ground in the wire.

NO -Go to step 10.

Check for continuity between power tilt/telescopic steering control unit connector A (16P) terminals and tilt/telescopic switch 13P connector terminals as shown:

CONTINUITY SPECIFICATIONS

TILT/TELESCOPIC SWITCH 13P CONNECTOR	POWER TILT/TELESCOPIC STEERING CONTROL UNIT CONNECTOR A (16P)
No. 1	No. 7
No. 3	No. 10
No. 6	No. 15
No. 7	No. 6
No. 10	No. 14

Fig 2: Checking Continuity Between Connector (16P) Terminals And Tilt/Telescopic Switch 13P Connector Terminals

Courtesy of AMERICAN HONDA MOTOR CO., INC.

Is there continuity?

YES -Replace the power tilt/telescopic steering control unit (see POWER TILT/TELESCOPIC STEERING CONTROL UNIT INPUT TEST/REPLACEMENT ).

NO -Repair an open or high resistance in the wire.
