Pre-Test Procedures - All Models
- Ensure battery is fully charged before making tests. Check all ignition wiring.
- DO NOT connect any condenser to terminal No. 1 of ignition coil. Connect and disconnect test instruments only when ignition is off. DO NOT touch or remove high tension wires when engine is running or cranking.
- Disconnect ignition wires only when ignition is off. DO NOT crank engine unless high tension wire is removed from distributor cap and grounded with a jumper wire.
- When installing suppressors, use only 1000 ohms for high tension wires and 1000-5000 ohms for spark plug connectors. DO NOT wash engine when it is running. DO NOT use a battery charger for more than one minute nor exceed 16.5 charging voltage.
