Window Switch

Use screwdriver to pry switch console from armrest. Remove wiring harness connectors. Carefully pry switch away from console at side tabs. See Fig 1 . Remove switch from console.

Fig 1: Removing Switch From Console

Courtesy of AUDI OF AMERICA, INC.
