Engine Number/Engine Specifications

Engine Number

• The engine number is first visible when the engine cover and the heat shield are removed.

  Courtesy of AUDI OF AMERICA, LLC

• The engine number is located at the rear top of the cylinder block.

1. Serial Number
2. Engine Codes

• There is also a label located on the upper timing chain cover with the "engine code" and "serial number".
• The engine code is also included on the vehicle data labels.

Engine Specifications

Engine code allocation. Refer to Engine Overview .
