Generators - BOSCH: Application

Model Part No.
Alfa Romeo
  Giulia 1600(1963-68)
    TI, Sprint, Spider (1) LJ/GEG 200/12/27 R. 32 mr
    All Others (2) EG (R) 14V25A29
BMW
  1500, 1600, 1800(1963-65) 0 101 206 060
  1800 ti (1963-66) (1) 0 120 400 523
  1600, 1602 (Before 8/67) 0 101 206 096
Mercedes Benz
  190C, 190DC(1963-65) 0 101 302 023 or 0 101 402 071
  220B, 220SB (1963-65) 0 101 302 023
  220SEB (1963-65) (2) G1 14V 30A 25
  300SE (1963-65) (2) K(R) 14V 38A 15
  300SEB (1965-67) (2) K(R) 14V 38A 15
  300SEL(1966-67) (2) K(R) 14V 50A 16
Opel
  All Models
    1100 Engine (1966-70) 0 101 206 120
    1500 Engine (1968-70) 0 101 206 150
Porsche
  356(1963-65) 0 101 206 029
  912(1966-69) 0 101 302 067 or 0 101 206 113
Renault
  R-1094 (1963-66) (2) U/GG 240/12/2400
  R-1095, R-1130 (1963-67) (2) U/GG 240/12/2400
  R-1131 (1963-65) (2) U/GG 240/12/2400
  R-l 132 (1965-66) (2) U/GG 240/12/2400
  R-1133 (1965-67) (2) U/GG 240/12/2400
Saab
  All Models (1965-66) 0 101 206 099
Volkswagen
  Type 1
    1963-64 101 212 001 or 101 212 004
    1965-66 (3) 101 212 066
    1967-68 101 302 067 or 101 302 068
      101 302 075
    1969-71 101 302 086
    1972101 302 118
    1973
    Except "The Thing" 101 302 117
    "The Thing" 101 302 111
Type 2
  1963-65 101 212 001 or 101 212 004
  1965 101 206 044 or 101 206 067
  1966 101 302 061
  1967-68 101 302 067 or 101 302 069
  1969 101 302 083
  1970-71 101 302 083 or 101 302 089
Type 3
  1966 101 206 044
  1967-68 101 302 069
  1969 101 302 089
  1970-71 101 302 090
  1972 101 302 114
  1973 101 302 113
Volvo
  544 (1963-66) 0 101 302 028
  122S (1967-68) 0 101 302 028
(1) Part number is an alternator and is used with a generator regulator, part number 0 190 350 044.
(2) Type number.
(3) Karmann Ghia uses generator part number 101 302 061.
Fig 1: Bosch Generator (Typical)
G09319087Courtesy of NOT AVAILABLE
