5.3.10. Seat belt warning light

A visual and audible warning is issued if the seat belt is not fastened or is unbuckled when the vehicle is in motion.

Fig 1: Display Seat Belt Warning Light
G06926665Courtesy of BMW OF NORTH AMERICA, INC.

The status of the seat belt buckle contacts of the seat bench is briefly visible in the TFT display of the instrument panel when the vehicle starts or a contact changes.
