Diagnostic Aids
An intermittent may be caused by a poor connection, rubbed through wire insulation or a wire broken inside the insulation. Check for:
- Poor Connection Or Damaged Harness: Inspect PCM harness connectors for backed out terminals, improper mating, broken locks, improperly formed or damaged terminals, poor terminal to wire connection and damaged harness.
- Intermittent Test: Monitor Tech 1 while moving related connectors and wiring harness. If failure is induced, scan data will change from low to high, or high to low. This may assist in isolating malfunction.
- Shifted Sensor: See TEMPERATURE-TO-RESISTANCE VALUES table to test sensor at various temperature levels to evaluate the possibility of a shifted sensor which may result in driveability complaints.
- A faulty connection, or an open in sensor circuits will cause Code P0117 to set.
TEMPERATURE-TO-RESISTANCE VALUES (1)
| Temperature °F (°C) | Ohms | ||
|---|---|---|---|
| 212 (100) | 177 | ||
| 194 (90) | 241 | ||
| 158 (70) | 467 | ||
| 104 (40) | 1459 | ||
| 68 (20) | 3520 | ||
| 23 (-5) | 12,300 | ||
| 14 (-10) | 16,180 | ||
| 0 (-18) | 25,000 | ||
| -4 (-20) | 28,680 | ||
| -22 (-30) | 52,700 | ||
| -40 (-40) | 100,700 | ||
|
|||
