Column Shift Indicator
- Position shift lever in "N" position. Position guide clip on edge of shift bowl to center position pointer on "N" position. Push clip onto bowl. Ensure that cable rests on bowl and not on column jacket.
- With gear selector in "N" position, holes must be visible on both sides of pointer. Pointer must cover portions of "1" or be to right of "1" when transaxle is in "LOW" position. See Fig 1.
