Driver or Passenger Seat Adjuster Memory Module Replacement

WARNING: This page is about a different car, the 2016 Chevrolet Malibu Limited. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Front Seat Heater Control Module & Fasteners

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Driver or Passenger Seat Adjuster Memory Module Fastener (Qty: 4) CAUTION: Refer to Fastener Caution .
2	Driver or Passenger Seat Adjuster Memory Module Procedure Disconnect the electrical connector. Disconnect the module from the bracket, then pull downward away from the bottom of the seat. Refer to Control Module References for programming and setup information.

Callout

Component Name

Driver or Passenger Seat Adjuster Memory Module Fastener (Qty: 4)

CAUTION: Refer to Fastener Caution .

Driver or Passenger Seat Adjuster Memory Module

Procedure

Disconnect the electrical connector.
Disconnect the module from the bracket, then pull downward away from the bottom of the seat.
Refer to Control Module References for programming and setup information.
