CCC Diagnosis: Notes
NOTE:
Federal "T" cars without 5-speed manual transmission do not have "long-term" memory capability. All codes stored in the memory will be erased when ignition switch is turned off. Memory is operational only while engine is running and problem or malfunction exists.
The ECM stores component failure information for CCC system under a related trouble code which can be recalled for diagnosis and repair. When recalled, these codes will be displayed by flashes of "CHECK ENGINE" lamp. Codes are displayed starting with lowest numbered code. Only codes in which a related malfunction has occurred will be displayed.
NOTE:
Example of trouble codes is as follows: "FLASH", "FLASH", "FLASH", pause, "FLASH", "FLASH", "FLASH" followed by a longer pause identifies trouble code "33". First series of flashes indicates first digit of trouble code; second series of flashes indicates second digit of trouble code.
