Wheel Alignment (Procedures): Caster
- Caster is the tilting of the front steering axis either forward or backward from vertical, as viewed from the side of the car. See Fig 1.
- When axis is tilted backward from vertical, caster is said to be positive. This creates a trailing action on front wheels. When axis is tilted forward, caster is negative, causing a leading action on front wheels.
