STOPLAMP Switch
NOTE:
Stoplamp switch is self-adjusting when installed properly in the fully locked position. The twist lock-type switches do not need any further adjustment.
- Slide the lower switch into the retainer until the switch plunger is fully depressed into the switch barrel.
- Twist the switch clockwise until travel has stopped. The switch connector will face the 8 o'clock position when the switch is fully locked. See Figure .
