Installation Procedure

CAUTION: Refer to BATTERY DISCONNECT CAUTION in Cautions and Notices.

Important: Clean any existing corrosion from the battery terminal bolt flange and the battery cable end.

Install the battery cable to the battery.
NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
Tighten the negative cable bolt.
Tighten

Tighten the bolt to 17 N.m (13 lb ft).

Fig 1: Installing Battery Cable To Battery
Courtesy of GENERAL MOTORS CORP.
