Label - Service Parts ID
| Callout | Component Name |
|---|---|
| 1 | Vehicle Identification Number |
| 2 | Wheel Base |
| 3 | Part Number Location |
| 4 | Model Designation |
| 5 | Order Number |
| 6 | Exterior Color |
| 7 | Paint Technology |
The service parts identification label is placed on the vehicle in order to help the service and parts personnel identify the vehicle's original parts and the vehicle's original options. The service parts identification label is located in the instrument panel (I/P) compartment.
