Coolant Temperature Sensor/Switch (For Computer): Locations

Engine Controls Component Views

Rear of the Engine (L37/LD8)




1 - Throttle Body Assembly
2 - Manifold Absolute Pressure (MAP) Sensor
3 - Valve Cover
4 - Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1
5 - Engine Coolant Temperature (ECT) Sensor
6 - Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2
