Installation Procedure

    Fig 1: Trailer Brake Control Module
    GM2127552Courtesy of GENERAL MOTORS CORP.
  1. Install the fuel pump flow control module (1). Refer to Fuel Pump Flow Control Module Replacement .
  2. If installing a new trailer brake control module, program the module. Refer to Control Module References .
