Inside Rearview Mirror Replacement
WARNING: This page is about a different car, the 2008 GMC Sierra, 2008 GMC Cab & Chassis Sierra, 2008 Chevrolet Silverado, and 2008 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Rearview Mirror Support Cover |
| 2 | Rearview Mirror Support Wire Cover Procedure: Disconnect the wiring harness from the rearview mirror. |
| 3 | Rearview Mirror Procedure: With both hands on the mirror, rock it from side to side while sliding upward, this will assist in the releasing of the mirror from the mounting tab. |
