Hybrid Powertrain Control Module 2 Replacement

Fig 1: Hybrid Powertrain Control Module 2

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Hybrid Powertrain Control Module 2 Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2	Hybrid Powertrain Control Module 2 Procedure Disconnect the electrical connectors. For programming and set up information, refer to Control Module References .

Callout

Component Name

Hybrid Powertrain Control Module 2 Fasteners (Qty: 4)

CAUTION:

Tighten
9 N.m (80 lb in)

Hybrid Powertrain Control Module 2

Procedure
