Engine Compartment Components - Left

Items
1. P13 Horn Assembly P13 Horn Assembly
2. G24 Windshield Washer Pump G24 Windshield Washer Pump
3. G52 Night Vision Camera Washer Pump (UV3) G52 Night Vision Camera Washer Pump (UV3)
4. B118B Windshield Washer Fluid Level Switch B118B Windshield Washer Fluid Level Switch
5. P25 Power Sounder Content Theft Deterrent Alarm Module (UTR) P25 Power Sounder Content Theft Deterrent Alarm Module (UTR+HP9)
6. F100L Hood Hinge Actuator - Left (B3T) F100L Hood Hinge Actuator - Left (B3T)
7. M75 Windshield Wiper Motor M75 Windshield Wiper Motor
8. B20 Brake Fluid Level Switch B20 Brake Fluid Level Switch
9. Q37LF Shock Absorber Actuator - Left Front (F55) Q37LF Shock Absorber Actuator - Left Front (F55)
10. K17 Electronic Brake Control Module K17 Electronic Brake Control Module (HP9)
11. X50A Fuse Block - Underhood X50A Fuse Block - Underhood X1 X50A Fuse Block - Underhood X2 X50A Fuse Block - Underhood X4 (LGW)X50A Fuse Block - Underhood X4 (LGX)X50A Fuse Block - Underhood X4 (LTG+HP9)X50A Fuse Block - Underhood X4 (LTG+KL9)X50A Fuse Block - Underhood X5
12. Q5 Brake Pressure Modulator

Fig 1: Engine Compartment Components - Left

Courtesy of GENERAL MOTORS COMPANY
