Intake Air Duct Replacement

Fig 1: Air Duct
GM4245487Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Front Compartment Front Sight Shield Replacement
1 Intake Air Duct Retainer [4x]
CAUTION: Refer to Fastener Caution .
2 Intake Air Duct [2x]
