Power Steering System: Specifications
Fastener Tightening Specifications
| Application |
Specification |
| Metric |
English |
| Power Steering Cooler to the Radiator Support Bolts |
5 N.m |
44 lb in |
| Power Steering Gear to the Frame Bolts |
135 N.m |
100 lb ft |
| Power Steering Hose Fittings |
28 N.m |
20 lb ft |
| Power Steering Pump Bolts |
50 N.m |
37 lb ft |
Courtesy of GENERAL MOTORS CORP.
