STOPLAMP Switch: Installation

  1. Install the stoplamp switch (2) to the brake pedal bracket. See Fig 1 .
  2. Connect the electrical connector to the stoplamp switch and adjust. See STOPLAMP SWITCH  under ADJUSTMENTS.
  3. Install the left side instrument panel insulator. See INSULATOR PANEL (LEFT SIDE)  .
Fig 1: Stoplamp Switch Replacement
G00060779Courtesy of GENERAL MOTORS CORP.
