Installation Procedure

    Fig 1: View of Air Cleaner Element
    GM1275964Courtesy of GENERAL MOTORS CORP.
  1. Install air cleaner element.
  2. Install rear air cleaner housing to front air cleaner housing.
    3. NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  3. Install front to rear air cleaner housing bolts.

    Tighten:  Tighten bolts to 3 N.m (27 lb in).

  4. Close the hood.
