Shift Lock Control Connector End Views

Automatic Transmission Shift Lever (North America)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		KET MG 610396 4-Way F Series Sealed (WH)
Pin	Wire Color	Circuit No.	Function
1	BK	1050	Ground
2	L-GN	275	Park/Neutral Position (PNP) Switch Signal
3	D-GN	286	Shift Lock Control Solenoid
4	PK	239	Ignition 1 Voltage

Automatic Transmission Shift Lever (Except North America)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		KET MG 610396 4-Way F Series Sealed (WH)
Pin	Wire Color	Circuit No.	Function
1	BK	1050	Ground
2	L-GN	275	Park/Neutral Position (PNP) Switch Signal
3	L-GN	275	Park/Neutral Position (PNP) Switch Signal
4	D-GN	286	Automatic Transmission Shift Lock Solenoid Supply Voltage

Key Interlock Module (North America)

Courtesy of GENERAL MOTORS CORP.
Connector Part Information		AK 36915 6-Way F Relay (BK)
Pin	Wire Color	Circuit No.	Function
30 (2)	YE	43	Accessory Voltage
31 (6)	BK	250	Ground
BK (7)	L-BU	20	Stop Lamp Switch Signal
P (8)	L-GN	275	Park Neutral Position (PNP) Switch Signal
SB (4)	D-GN	286	Shift Lock Control Solenoid Control
SK (5)	YE	1075	Park Neutral Position (PNP) Switch Signal
