Removal Procedure
- Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnect/Connect Procedure (7.0L) in Engine Electrical.
- Remove the engine sight covers. Refer to Engine Sight Shield Replacement in Engine Mechanical - 6.0L.
- Relieve the fuel system pressure. Refer to Fuel Pressure Relief Procedure .
- Using compressed air, clean the fuel injector and intake manifold.
- Disconnect the fuel feed line (1) from the fuel rail (2).
- Mark the fuel injector to the electrical connector. Disconnect the electrical connectors.
- Remove the intake manifold bolts (3).
- Remove the mounting bolts for the fuel rail (4).
- Remove the fuel rail assembly (2) from the intake manifold (10).
- Remove the fuel injectors (7) from the fuel rail. Refer to Fuel Injector Replacement .
CAUTION:
Refer to Battery Disconnect Caution
in Cautions and Notices.
IMPORTANT:
Before disconnecting the electrical connectors, mark the relationship of the electrical connector to the fuel rail injector fitting. This will ensure the proper electrical connector sequence for reassembly.
