Ambient Light Sensor Replacement

WARNING: This page is about a different car, the 2006 Buick Lucerne. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Ambient Light Sensor

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Instrument Panel Upper Trim Pad Refer to Instrument Panel Upper Trim Pad Replacement .
2	Headlamp Auto Control Ambient Light Sensor Tip: Twist and pull out of the instrument panel upper trim pad. Disconnect the electrical connectors.
