Brake Pedal Position Sensor Replacement

WARNING: This page is about a different car, the 2006 Buick Lucerne. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Brake Pedal Position Sensor

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedure: Remove the accelerator pedal. Refer to Accelerator Pedal Position Sensor Replacement .
1	Accelerator Pedal Assembly Nut (Qty: 3) NOTE: Refer to Fastener Notice . Tighten: 9 N.m (80 lb in)
2	Accelerator Pedal Assembly
3	Brake Pedal Position Sensor Bolt Tighten: 2 N.m (18 lb in)
4	Brake Pedal Position Sensor Tip: Disconnect the electrical connector. Calibrate the brake pedal position sensor. Refer to Brake Pedal Position Sensor Calibration .
