Memory Positioning Module: Locations

Passenger Compartment/Roof Component Views

Driver Seat Components




1 - Seat Belt Switch - Left
2 - Seat Back Cover
3 - Heated Seat Element - Driver Back (KA1)
4 - Inflatable Restraint Side Impact Module - Left (AJ7/AW9), Inflatable Restraint Side Impact Module - Left Rear (AW9) Similar
5 - Memory Seat Module - Driver (AG0)
6 - Seat Adjuster Motor Assembly - Driver (AG0/AG1)
7 - Seat Adjuster Switch - Driver (AG0/AG1)
8 - Heated Seat Element - Driver Cushion (KA1)
9 - Seat Cushion Cover
