Intake Air Temperature Sensor Replacement

Fig 1: Intake Air Temperature Sensor
GM2027430Courtesy of GENERAL MOTORS COMPANY
Intake Air Temperature Sensor Replacement

Callout Component Name
1 Intake Air Temperature Sensor Assembly
CAUTION:

Any time service is being performed which requires removal of the air cleaner assembly, always cover the throttle body opening. This will prevent any foreign material from entering the engine.

2 Intake Air Temperature Sensor Cable Clip
