Body Control Module Replacement

Fig 1: Body Control Module

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Transmission Control Replacement (With Base)Transmission Control Replacement (Without Base)
1	Body Control Module Procedure Release the retaining tabs. Control Module References for programming and set up information, if required.

Callout

Component Name

Body Control Module

Procedure
