Side View Mirror Flag: Removal

  1. Open front door.
  2. Remove fastenters attaching the front door flag enclosure cover to the door. Remove the speaker from the cover, if necessary. See Fig 1 .
  3. Remove fasteners attaching the front door flag enclosure plate to front door, if necessary. To install, reverse the removal procedure.
Fig 1: Removing Mirror Flag Encloser
G00232513Courtesy of CHRYSLER CORP.
