Accelerator Pedal Position Sensor: Description

The accelerator pedal position sensor (1) is located inside the accelerator pedal. The accelerator pedal position sensor (1) can not be serviced by itself. The accelerator pedal must be replaced as a unit. See ACCELERATOR PEDAL .

Fig 1: Locating Accelerator Pedal Position Sensor

Courtesy of DAIMLERCHRYSLER CORP.
