Connecting Rod, Engine

CONNECTING ROD

Lubricate the new rod cap bolts with clean engine oil
Install and tighten 21 Nm (15 ft. lbs.) plus 90°.






CONNECTING ROD






CONNECTING ROD JOURNALS

Connecting Rod Journal Diameter 53.992 - 54.008 mm (2.126 in.)
Out Of Round(MAX) 0.018 mm (0.0007 in.)
