Installation 3.6L Gasoline Engine
NOTE:
Before installing power steering pressure hose on power steering pump, replace O-ring on end of power steering pressure hose. Lubricate O-ring using clean power steering fluid.
- Install power steering pump (2) onto its mounting bracket (5).
- Install the three power steering pump mounting bolts and spacers and tighten to the proper torque specification. Refer to TECHNICAL SPECIFICATIONS .
- Install power steering pump pressure fitting (4) and tighten to the proper torque specification. Refer to TECHNICAL SPECIFICATIONS .
- Slide fluid supply hose onto pump (3) fitting and install clamp securing it in place.
- Install the power steering pump pulley. Refer to PULLEY, POWER STEERING PUMP, INSTALLATION .
- Lower vehicle.
- Connect negative (-) battery cable on negative battery post.
- Fill and bleed power steering system. Refer to STANDARD PROCEDURE .
- Inspect for leaks.
