Connector End Views & Electrical Component Locations (2 Of 3): Module-Inverter

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1456471-1

Part Description: 8P UNSEALED HYBRID PLUG ASSEMBLY

Connector No: D3920A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Module-Inverter Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Inverter Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P809

LG/WT

1.0

110 VOLT AC COMMON

115 VAC

A999

RD/LG

2.5

FUSED B(+)

115 VAC

P801

1.0

110 VOLT AC LINE 1

115 VAC

F996

LG/RD

0.35

FUSED IGNITION SWITCH OUTPUT (RUN-ACC)

115 VAC

Z941

2.5

GROUND

115 VAC

⁽¹⁾	Pins not listed are not used for this connector
