Service Code-To-Test Menu
SERVICE CODE REFERENCE CHART
| Service Code | Circuit Affected | Perform Test |
|---|---|---|
| 01 | IDM | A1 |
| 02 | CPS | A2 |
| 03 | CID1 | A3 |
| 04 | CID1 | A4 |
| 05 | KS & KCU | A5 |
| Vehicle Battery | N/A | A6 |
| Referance Voltage & Signal | N/A | A7 |
| 06 | VSS | B1 |
| 08 | VAF | B2 |
| 09 | ECT | B3 |
| 10 | VAT | B4 |
| 12 | TPS | B5 |
| 14 | BP | B6 |
| 15 | EGO | C1 |
| 16 | EVP | C2 |
| 17 | EGO | C1 |
| 25 | PRC | C3 |
| 26 | CANP | C4 |
| 28 (Turbo) | EGRC | C5 |
| 28 (Non-Turbo) | EVR | C6 |
| 29 (Turbo) | EGRV | C5 |
| 34 | ISC | D1 |
| 42 | BOOST | D2 |
| Self-Test Input | N/A | D3 |
| Self-Test Output | N/A | D3 |
