Cable Bracket - 2.0L SPI: Installation

To install, reverse the removal procedure.
- Adjust the accelerator cable; refer to CABLE ADJUSTMENT .
- Adjust the speed control actuator cable; refer to VEHICLE SPEED CONTROL .
Fig 1: Installing Accelerator Cable Bracket
Courtesy of FORD MOTOR CO.

Fig 2: Installing Speed Control Actuator Cable
Courtesy of FORD MOTOR CO.
