Oil Pump: Notes

SPECIAL TOOL(S)

G04660391Courtesy of FORD MOTOR CO.
 Engine Lift Bracket Set 303-D095 (D94L-6001-A)
MATERIALS

Item Specification
Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent WSS-M2C930-A
Fig 1: Oil Pump Replacement Components With Torque Specifications
G04660392Courtesy of FORD MOTOR CO.
