| 1 |
* |
* |
Not Used |
|
| 2 |
* |
* |
Not Used |
|
| 3 |
CRW10 (BU-GN) |
22 |
SWITCH - FRONT WIPER LOW |
|
| 4 |
CLS32 (BN-YE) |
22 |
SWITCH - HAZARD |
|
| 5 |
* |
* |
Not Used |
|
| 6 |
CRW18 (VT-WH) |
22 |
SWITCH - FRONT WIPER INTERVAL (B) |
|
| 7 |
* |
* |
Not Used |
|
| 8 |
CPL75 (BN-WH) |
22 |
RELAY - DOOR LOCK # ALL LOCK |
|
| 9 |
CRW08 (VT-OG) |
22 |
SWITCH - FRONT WIPER HIGH (H) |
|
| 10 |
CLF17 (WH-OG) |
22 |
SWITCH - BEAM HIGH |
|
| 11 |
CRD04 (BN-GN) |
22 |
INDICATOR - HEATER REAR WINDOW |
|
| 12 |
* |
* |
Not Used |
|
| 13 |
* |
* |
Not Used |
|
| 14 |
* |
* |
Not Used |
|
| 15 |
* |
* |
Not Used |
|
| 16 |
CRW17 (GN-VT) |
22 |
SWITCH - FRONT WIPER INTERVAL (A) |
|
| 17 |
* |
* |
Not Used |
|
| 18 |
* |
* |
Not Used |
|
| 19 |
* |
* |
Not Used |
|
| 20 |
* |
* |
Not Used |
|
| 21 |
* |
* |
Not Used |
|
| 22 |
* |
* |
Not Used |
|
| 23 |
VDB07 (VT-OG) |
20 |
CONNECTOR - DIAGNOSTIC # CAN BUS MEDIUM SPEED LOW |
|
| 24 |
VDB06 (GY-OG) |
20 |
CONNECTOR - DIAGNOSTIC # CAN BUS MEDIUM SPEED HIGH |
|
