Powertrain Control Module (PCM): Removal
- 1.NOTE: This step is only necessary when installing a new component.
Download the module information to the diagnostic tool using the Programmable Modules Installation routine. Use the General Equipment: Ford Diagnostic Equipment
- 2.
Disconnect the battery connections. Refer to: Battery Disconnect and Connect .
- 3.
Remove the fender splash shield. Refer to: Fender Splash Shield .
