Instruments - Instrument Cluster Display Message 'LA 13'

Instrument cluster display message "LA 13"

Topic number LI54.30-N-048713

Version 1

Design group 54.30 Instrument cluster/display instruments/warning devices

Date 01-14-2010

Validity Model 906.### ## 419430 up to 430542

Reason for change

Reason for block

Complaint:
The message "LA 13" appears on the instrument cluster display.

Cause:
Software error in instrument cluster.

Remedy:
Flash instrument cluster.

The new software is available as of SDS version 11/2009.





Replacing the instrument cluster is not permissible!
