Sensor-Intrusion 2

Component ID: 470
Component : SENSOR-INTRUSION 2

Connector:
Name : SENSOR-INTRUSION 2
Color :
# of pins : 4




Pin Description Circuit
1 GROUND 2281 20BR
2 - 2272 20YL/DB
3 - U245 20BK/DB
4 - U762 20RD/DB
