Sensor-Intrusion 3


Component ID: 471
Component : SENSOR-INTRUSION 3

Connector:
Name : SENSOR-INTRUSION 3
Color :
# of pins : 4




Pin Description Circuit
1 GROUND 2282 20BR
2 - 2270 20WT/DB
3 - U245 20BK/DB
4 - U762 20RD/DB
