Lamp-Ceiling 2-Rear

Component ID: 218
Component : LAMP-CEILING 2-REAR

Connector:
Name : LAMP-CEILING 2-REAR C1
Color : BLACK
# of pins : 1




Pin Description Circuit
1 GROUND U1036 18BR/DB



Connector:
Name : LAMP-CEILING 2-REAR C2
Color : BLACK
# of pins : 1




Pin Description Circuit
1 FUSED B(+) U41 18RD
