Module-Electric Brake Control

Component ID: 263
Component : MODULE-ELECTRIC BRAKE CONTROL

Connector:
Name : MODULE-ELECTRIC BRAKE CONTROL
Color :
# of pins : 4




Pin Description Circuit
1 FUSED B(+) 3944 12RD/YL
2 GROUND 3945 12BR
3 ELECTRIC BRAKES INPUT 3936 BK/RD
4 ELECTRIC BRAKES OUTPUT 3940 12BK/DB



Connector:
Name : MODULE-ELECTRIC BRAKE CONTROL
Color :
# of pins : 4




Pin Description Circuit
1 FUSED B(+) 3944 12RD/YL
2 GROUND 3945 12BR
3 ELECTRIC BRAKES INPUT 3936 BK/RD
4 ELECTRIC BRAKES OUTPUT 3940 12BK/DB
