Sensor-Headlamp Level-Rear

Component ID: 466
Component : SENSOR-HEADLAMP LEVEL-REAR

Connector:
Name : SENSOR-HEADLAMP LEVEL-REAR
Color :
# of pins : 4
Gender : FEMALE




Pin Description Circuit
1 SENSOR GROUND 2474 20WT/BR
2 SENSOR SUPPLY 2476 20WT/RD
3 - -
4 REAR HEADLAMP LEVEL SIGNAL 2475 20WT/DG
