Sensor-Inlet Air Pressure

Component ID: 467
Component : SENSOR-INLET AIR PRESSURE

Connector:
Name : SENSOR-INLET AIR PRESSURE
Color : BLACK
# of pins : 2
Qualifier : (DIESEL)
Gender : FEMALE




Pin Description Circuit
1 INLET AIR PRESSURE SENSOR GROUND 1315 20VT/BR
2 INLET AIR PRESSURE SENSOR SIGNAL 1330 20VT/YL
3 INLET AIR PRESSURE SENSOR 5 VOLT SUPPLY 156 20PK/VT
