Power Window System Operation Check
Check condition of ACC/IGN circuit breaker. If circuit breaker is in good condition, repair by symptom. See SYMPTOM INDEX table under SYSTEM TESTS.
Diagnosis of the power windows can be preformed in the flowing flowchart. See Fig 1 .
